SystemVerilog Class Assignment

Class Assignment


Object will be created only after doing new to an class handle,

packet   pkt_1;
pkt_1  = new();
packet   pkt_2;
pkt_2  = pkt_1;

In above piece of code,

  • object is created only for pkt_1, pkt_2 is just an handle to the packet
  • pkt_1 is assigned to the pkt_2. so only one object has been created, pkt_1 and pkt_2 are two handles both are pointing to the same object
  • As both the handles are pointing to the same object any changes made with-respect to pkt_1 will reflect on pkt_2

Class assignment
SystemVerilog Class Assignment

Class assignment example


The below example shows,
access to static properties and static methods,and access to static class properties and methods are accessed without creating an object.



class packet;
  //class properties
  bit [31:0] addr;
  bit [31:0] data;
  bit write;
  string pkt_type;
  //constructor
  function new();
    addr  = 32'h10;
    data  = 32'hFF;
    write = 1;
    pkt_type = "GOOD_PKT";
  endfunction

  //method to display class properties
  function void display();
    $display("---------------------------------------------------------");
    $display("\t addr  = %0d",addr);
    $display("\t data  = %0h",data);
    $display("\t write = %0d",write);
    $display("\t pkt_type  = %0s",pkt_type);
    $display("---------------------------------------------------------");
  endfunction
endclass
module class_assignment;
  packet pkt_1;
  packet pkt_2;

  initial begin
    pkt_1 = new();
    $display("\t****  calling pkt_1 display  ****");
    pkt_1.display();
    //assigning pkt_1 to pkt_2
    pkt_2 = pkt_1;
    $display("\t****  calling pkt_2 display  ****");
    pkt_2.display();
    //changing values with pkt_2 handle
    pkt_2.addr = 32'hAB;
    pkt_2.pkt_type = "BAD_PKT";

    //changes made with pkt_2 handle will reflect on pkt_1
    $display("\t****  calling pkt_1 display  ****");
    pkt_1.display();
  end
endmodule


 Simulator Output

****calling pkt_1 display****
---------------------------------------------------------
addr = 16
data = ff
write = 1
pkt_type = GOOD_PKT
---------------------------------------------------------
****calling pkt_2 display****
---------------------------------------------------------
addr = 16
data = ff
write = 1
pkt_type = GOOD_PKT
---------------------------------------------------------
****calling pkt_1 display****
---------------------------------------------------------
addr = 171
data = ff
write = 1
pkt_type = BAD_PKT
---------------------------------------------------------
